To learn how to install ball bearing slide in 1 minute!

2,385 Published by May 13,2020

1
There are plastic parts at the ends and sides of the ball bearing slide. Please do not hammer with hard rocket tools during installation. During the trial operation after installation, do not allow any objects to impact on it during overspeed. If the plastic parts break, the ball will Roll out, the slider will fall
2
Before the ball bearing slide leaves the factory, the family has lubricating oil. If you want to clean it, you must dry it first. Live the lubricating oil at home. It is strictly forbidden to run the ball bearing slide without lubrication.
3
Do not remove the slider from the linear guide if it is not necessary. If you do not want to uninstall, you must first align the auxiliary linear guide before removing the slider
4
It is strictly forbidden to disassemble all parts of the ball bearing slide at will, which affects the accuracy and flexibility on one side, and it is strictly forbidden to add ball bearings that do not meet the regulations to the ball bearing slide at will
Replacement procedure of CSK ball bearing slide
1. Remove the baffle on both sides of the motor
When removing the baffle, pay attention to the optical fiber. Handle it gently to avoid breaking the fiber.
2. Check for debris on the motor
We need to clean the debris and foreign objects in the motor in time, and wipe the motor and motor guide rail clean.
3. Move the walking arm gently by hand to check the guide rail slider
1) When the resistance is high, it is necessary to clean the ball bearing slide of the walking arm. Wipe the guide rail with cotton cloth. After cleaning, use WD40 as an auxiliary cleaning agent to clean the foreign objects on the edge of the guide rail.
2) After cleaning, touch the edge of the guide rail with your hands and slowly move in the same direction to check whether the guide rail is worn. When you feel a burr on your finger, you need to pay attention to check it. It may be that the guide rail is worn. At this time, use Slowly push the walking arm with your hand to see if the resistance of the slider here is relatively large, and whether the walking arm is very difficult to push. When the resistance is relatively large, the guide rail needs to be replaced immediately.
3) When wiping the motor, pay attention to whether there are small marbles in the motor. If you find marbles, you need to clean them and replace the slider.
4) Gently push the walking arm to listen to the sound of the slider when sliding. If the friction is loud, you need to replace the slider.
5) Check whether the air gap between the stator and rotor of the motor is consistent before and after, and the inconsistency between the front and back will easily cause the service life of the guide rail and the slider to be reduced; then it needs to be adjusted.
6) Carefully observe whether the marble of the slider matches the groove of the guide rail.
