Do you know the installation and disassembly of ge es spherical bearing?

ge es spherical bearing installation and disassembly
1. Where there is a lack or inability to use the press, an end sleeve joint bearing can be installed with an assembly sleeve and a hammer. The hammering force should be evenly transmitted to the entire circumference of the end face of the ge es spherical bearing ring, so the end face of the assembly sleeve that is hit by the hammer should be made spherical.

2. The force required to install the end rod articulated bearing is related to the size of the articulated bearing and the size of the interference fit. For medium or large ge es spherical bearing with a large interference amount, hot fitting is commonly used. Put the end-rod joint bearing or separable joint bearing ring in the oil tank or special heater before hot-packing, and heat it evenly to 80-100℃, not to exceed 100℃.　　

3. Hot-fitting ge es spherical bearing require skilled operation skills. After the joint bearing is removed from the heating oil tank or heater, immediately wipe off the oil stains and attachments on the surface of the joint bearing with a clean cloth (note that cotton yarn cannot be used), and then put it in front of the mating surface. The articulated bearing is pushed against the shoulder of the shaft. During the cooling process, you should always push it tightly, or tap the joint bearing through the assembly sleeve with a hammer to make it tight. When installing the end rod joint bearing, the joint bearing should be rotated slightly to avoid tipping or jamming during installation.　　

4. When the outer ring of the ge es spherical bearing and the housing hole are in tight fit, the housing can be heated and then installed into the joint bearing. In particular, the joint bearing of light metal material may cause damage to the mating surface due to the pressing of its outer ring during the tight fitting process. In this case, the end rod joint bearing should be heated first.
