Do you know the linear bearing pillow block?

The linear bearing pillow block is a linear motion system that is produced at low cost and is used with an infinite stroke in conjunction with a cylindrical shaft. Since the carrier ball is in point contact with the shaft, the load used is small. The steel ball rotates with a very small frictional resistance, so that smooth motion with high precision can be obtained.

Linear bearing pillow block
Linear bearing pillow block is widely used in electronic equipment, tensile testing machines and digital three-dimensional coordinate measuring equipment and other precision equipment, as well as multi-axis machine tools, punching machines, tool grinding machines, automatic gas cutting machines, printers, card sorting machines, food packaging machines and other industrial machinery. Sliding parts.

Linear bearing pillow block features
1, linear bearing pillow block corrosion resistance and rust resistance. Linear bearing housing, mandrel bearing, made of aluminum alloy, processed surface after plating.
2, linear bearing pillow block assembly interchange is easy. Linear bearing housings have been standardized, standardized and rigorously precise, so it is easy to meet customer requirements in terms of assembly or maintenance interchangeability.
3, linear bearing pillow block runs smoothly, low noise. The series of bearing housings slide in contact with the mandrel and the frictional resistance is extremely small.

Linear bearing pillow block classification:

(1) Standard type, gap-adjustable linear bearings, open-type linear bearings, and extended linear bearings.

(2) Flange type linear bearings can be divided into: round flange type, method blue type, elliptical flange type, guide round flange type, guide method blue type, guide elliptical flange type, extended round flange type, lengthened Methods Lan type, extended elliptical flange type, guide lengthened round flange type, guide lengthening method blue type, guide lengthened elliptical flange type, lengthened intermediate round flange type, lengthened intermediate method blue type, extended middle elliptical flange type.

The linear bearing pillow block is divided according to the specifications:

The linear bearing pillow block is divided into two series, LM and LME series. Its code name LM series is used in Asia, Southeast Asian countries, Japan, Korea, China and so on. In terms of metric size, the tolerance of the outer diameter of the linear shaft is generally h7. The LME series is mostly used in Europe, the United States, Germany, Italy and other regions. In the inch size, there are also metric sizes, and the tolerance of the outer diameter of the linear shaft is generally g6. Two series of structural features, in addition to different sizes, different aperture tolerances, the structure is roughly the same.

ZYSL company specializes in linear bearing pillow block for many years. All raw materials and accessories have been carefully selected to ensure a good user experience.

Welcome to contact us!
