What are the characteristics of the pillow block bearing assembly?

The characteristics of the pillow block bearing assembly:

The pillow block bearing assembly is a bearing unit that combines a rolling bearing with a bearing housing. Most outer spherical bearings are made with a spherical surface and with a ball.
The inlet housings of the inner bores are installed together, with various structural forms, good versatility and interchangeability.

At the same time, these bearings are also designed with a certain degree of self-alignment, easy to install, and have a double-structured sealing device that can work in harsh environments. The bearing housing is typically cast. Commonly used seats are vertical seat (P), square seat (F), boss square seat (FS), boss circular seat (FC), diamond seat (FL), ring seat (C), slider seat, etc. T).
Pillow block bearing assembly type of inserted bearing:
l, with a set screw outer spherical surface UC bearing;
2, with a tapered hole outer spherical surface UK bearing;

The pillow block bearing assembly is a high-precision component that combines grease-sealed deep groove ball bearings with various shapes of housings. The bearing assembly can be directly mounted to the main body of the mechanical device through several bolts, has a self-aligning function, can be supplemented with grease, etc., and is a product that is very easy to install and use for.

Pillow block bearing assembly is divided into insert bearing and bearing seat, which is called insert bearing plus bearing seat designation, such as spherical bearing with set screw UC205 with vertical seat called UCP205. Pillow block bearing assembly Because of its strong interchangeability, the insert bearing can be assembled freely in the bearing housing of the same size and shape.

Vertical block bearing assembly (UCP205)
Square block block bearing assembly (UCF205)
Diamond block bearing assembly (UCFL205)
Boss round block bearing assembly (UCFC205)
Circular block bearing assembly (UCC205)
Slide block block assembly (UCT205)
Suspended pillow block bearing assembly (UCHA205)
