What is the difference between the rubber bearing and the steel bearing?

On the outside of the gear box, the end cover that blocks the outer ring of the bearing, or the end cover that blocks the bearing hole, is called the bearing cover. The rubber cover and iron cover of the bearing are what we will encounter more often.
So what is the difference between the rubber bearing and the steel bearing? What are the advantages of each? What is the main use?

The function of the bearing end cover is to axially fix the bearing, and secondly, it plays the role of sealing and protection to prevent the bearing from entering the bearing and causing damage to the bearing.
The bearing end cover is fixed on the bearing seat or bearing chamber. If it is fixed on the shaft, the diameter of the seal will be enlarged and the seal will be difficult.

1. The purpose of the rubber bearing is mainly to prevent dust, and it can also be prevented by being tightly sealed; but the friction is large, and the speed is lower than that of the iron cover, so the heat dissipation performance is worse than that of the iron cover, and the plastic cover is also divided into contact and non-contact. , but the specificity is almost the same, that is, there is a little difference in sealing and friction.

2. The iron cover has many uses, mainly for dust prevention. The speed of the iron cover is high. However, because it is made of iron, it is not waterproof, but the rubber cover has greater friction, so the heat dissipation performance is also worse than that of the iron cover. And in terms of speed, the rubber cover is also lower than the iron cover. The operating temperature of the bearing, the general operating temperature of the bearing rubber cover should not exceed 150 ℃.
2Z: Stamped steel plate bearing dust cover: It reduces the leakage of bacteria and reinforces the metal steel plate on the outer ring by stamping.

Sealing ring: The sealing ring is an annular cover composed of one or several parts, which is fixed on one ring or washer of the bearing and contacts with another ring or washer or forms a narrow labyrinth gap to prevent the leakage of lubricating oil and the intrusion.

TT: retaining ring type Teflon bearing sealing ring: mainly used for miniature bearings, the structure of the Teflon sealing ring added with glass fiber is fixed on the outer ring with a spring tight ring.

2RS: Contact rubber bearing sealing ring: Effectively prevent the intrusion of external foreign matter, the rubber sealing ring is embedded in the outer ring of the bearing, and the sealing ring is in slight contact with the inner ring.
